D5510

Interactive Whiteboard

ID: 730-431193

Select from the options below for support and more

Download Manuals

How-To-Videos

Learn about common tasks, topics and features as explained in more than 150 short video tutorials for our most popular devices.

Download Brochure

MyRicoh

If you are a current Ricoh Customer, you can use MyRicoh to get support for your products, purchase supplies, and much more.

Operating System	Windows Embedded Standard 7

Video Input	Display unit: Mini D-SUB15pin x 2, DisplayPort, HDMI (HDCP x 1), HDMI (PC) x 1
Video Output	DVI x 1
Audio Output	Pin plugs (R+L) and terminals for 10W + 10W speakers
Interfaces	USB port: USB2.0 TYPE-A x 2, USB3.0 TYPE-A x 2, Wired LAN: 10BASE-T/100BASE-T/ 1000BASE-T, DVI x 1, Wireless LAN: Available with Wi-Fi converter (not supplied by Ricoh)
Dimensions W x D x H	53.5" x 4.92" x 32.7" (1,360 x 125 x 830 mm)
Weight	Less than 99 lbs. (45 kg)
Power Source	100 - 240 V, 50/60 Hz
User functions	20 color pen, Select, Delete (Erase), Undo/Redo, Save to USB/Network Folder/ Interactive Whiteboard, Open PDF and PPT files from USB and Network Folder, Screen Page Select, Capture Page, Add New Page, Captured Page List, Delete Page, Copy Page, Marker Function, Auto Firmware Download
Enhanced features	Picture in Picture, Zooming, Recovery function, Email, Page Print, Data saving form: PDF v1.4, Max. page creation: 100, and Max. strokes/page: 3,000
Remote sharing function	Up to 8 Interactive Whiteboards and Projector Systems Up to 20 browser viewers per Interactive Whiteboard
Remote PC Operation	Yes
Other Features	Detection system electronic pen: Light interception method Protection Glass Thickness: Approx. 2mm (including AR coating)
Other	Brightness will depend on input mode and other picture settings.

Noise	Less than 40dB
Power Consumption	Less than 200W
Start-up time	Less than 50 sec.
Stand-by mode	Less than 45W
Recovery time from stand-by mode	About 5 sec.
Operating temperature	10°C - 32°C
Operating humidity	15% - 80%
Altitude limitation	Lower than 2,000m (sea level)

CPU	Intel iCore3 4330 3.5GHz
Operating Systems	Windows Embedded Standard 7 (64-bit)
SSD	80GB
RAM	8GB
